Qsep100
Bio-Fragment Analyzer
Qsep100 Bio-Fragment Analyzers is the most versatile instrument of the Qsep Series Bio-Fragment Analyzers. It provides consistent high precision analysis by using the same single-channel cartridge as the Qsep1. It provides flexible sample capacity from 1 to 100samples. Qsep100 is commonly used in general research laboratories and also a good partner for the NGS QC laboratories. Moreover, with diverse cartridges, Qsep100 could apply to DNA, RNA analysis. It must be a powerful tool for Life Science, Agriculture, Pharmaceutical Industry, and Food Science research.
Specification | Highlights | ||
Detection | Fluorescence | System Type | Standard System |
Light Source | LED | Automated Sampling | 1~100 samples |
Separated Voltage | 1~15kv | Disposable Gel-Cartridge (100~200 sample capacity without gel preparation) | Single Channel Cartridge： ·DNA: S1,S2, S3, N1,N3,F3 ·RNA: R1,NR1 ·Protein：P2 |
Connection | USB | Rapid Analysis | 1~7mins/sample (below 1 kb) |
Power Source | AC 110-240V | Resolution | 1~4bp (below 500bp) |
Minimum Power | 30W | Sensitivity | 1pg/μL |
System Weight | 15kg | Minimum Sample volume | 1μL(Micro Vial, C104250) 10μL(0.ImL Tube) 20μL(0.2mL Tube) |
Dimension | 38*30*40cm | Sample Consumption | ≤1μL |
Software: Q-Analyzer | ·Relative qualitative and quantitative analysis Electrophoresis ·Gel view image ·Customer-oriented report | ||
